The Evolution is an eight thread overlocker/coverstitch machine including:
Features:
-
79 stitch options
-
ExtraordinAir Treading
-
Automatic Thread Delivery System
-
Heavy Duty cutting system
-
Exclusive wave stitch and reverse wave stitch
-
Automatic rolled hem stitch
-
Coverstitch options and more!
What's In The Box
- Instruction manual
- Quick reference threading guide
- Combination foot control & power cord
- Package of assorted sized needles Organ ELx705CF
- Flat table for chain/cover stitching
- 2 x Guide fixing screws for table
- Lint brush/needle insert tool
- Manual needle threader
- Allen screwdriver
- Tweezers
- Upper cutting blade for replacement
- Screwdriver
- Looper threading tool
- 2 x Overlock needle screws
- 2 x Chain/cover stitch needle screws
- 8 x Thread nets
- 8 x Spool caps with sponge
- 8 x Spool caps
- Machine cover
- 8 x Cone holders
- Standard grooved presser foot
- Thread stand extension
- Thread guide extension
| Specifications | |
|---|---|
| Machine Type | 8-Thread Overlocker |
| Machine Type | Coverstitch |
| Threading System | ExtraordinAir™ |
| Key Technology | |
| Number of Threads | 8 |
| RevolutionAir™ Threading – Needles & Loopers | |
| ExtraordinAir™ Threading | |
| NEW JetAir™ (easier looper threader engagement) | |
| JetAir™ Threading | |
| Tension System | Auto Thread Delivery (ATD) System |
| Lighting | 3 LED |
| Throat Space | - |
| True 2 to 1 ratio differential feed - ranging from 0.6 to 2 | |
| Knee Lift (Presser Foot) | |
| Variable Speed Control (easily set the maximum speed) | |
| Exclusive Fabric Support System | |
| Vertical Needle System – minimises needle deflection | |
| Advanced Features | |
| Combination Stitch Options | 87 |
| Coverstitch: triple, wide (6mm), narrow (3mm) & single chain stitch | |
| Overlocking stitch Options: 4/3/2 Thread | |
| Exclusive Wave Stitch and Reverse Wave Stitch | |
| Automatic rolled hem stitch with the turn of a dial | |
| Flatlock stitch option for seaming and decorative effects | |
| Stitch Length | 0.75 to 4mm |
| Stitch Width – Overlocking | 1.5 to 7.5mm |
| Stitch Width – Expressive (overlocking & coverstitch combined) | Up to 16mm |
| Heavy duty cutting system – cut thick fabrics easily | |
| Presser Foot Pressure Adjustment | Adjustable Screw |
| Presser Foot Height | 4.5mm |
| Sewing speed (stitches per minute) | up to 1500 |
| Convenience Features | |
| Thread Stand Tray with Magnet | |
| Colour Coded Quick Reference Threading Guide | |
| Built-in Manual Needle Threader | |
| Position of presser foot lever | Rear |
| Included Foot | Grooved Foot |
| Built in Thread Cutter | |
| Guard plate for needle screws | |
| Built in Accessory Storage | |
| Saftey Switches | 2 |
| Needle Drop Tray | |
| Electronic Foot Control | |
| Other Features | |
| Needle Type | EL 705 CF |
| Machine Weight | 8.5KG |
| Made in Japan & 5 Year Conditional Warranty | |
| Optional Accessories | |
| Optional Feet Available | 16 |
| Optional Attachments | 13 |
| Compatibility with Knit Binders/Lap Seam Binder | |
| Clear Extension Table Compatibility | CT-1 |
| SKU | BLE8W-2 |
|---|---|
| Brand | Baby Lock |
| Number Of Threads | 2-8 |
| Max Number Of Threads | 8 |
| Differential Feed | 0.5mm to 2.00mm Ratio |
| Number Of Stitch Combination Options | 87 |
| Flatlocking | Yes |
| Rolled Hemming | Yes |
| Cover Hem | Yes |
| Top Cover Hemming | No |
| Chain Stitch | Yes |
| Wave Stitch | Yes |
| Threading Chart | Yes |
| Adjustable Cutting Width | 3 to 7.5mm |
| Adjustable Stitch Length | 0.75mm to 4.0mm |
| Retractable Upper Knife | Yes |
| Two Thread Converter | Yes |
| Waste Tray Included | No |
| Tension System | Auto Thread Delivery (ATD) System |
| Air Threading (looper) | ExtraordinAir |
| Quick Change To Rolled Hem | Yes |
| Mechanical Warranty | 5 Years |
| Machine Weight | 9.5kg |
| Machine Height | 270mm |
| Machine Length | 350mm |
| Machine Depth | 360mm |
| Workspace | 2" |
| Lighting Type | LED |
| Number Of Lights | 3 |
| USB Port | No |
| Wi-Fi Enabled | No |
| Thread Cutter | No |
| Needle Threading | No |
| Stitch Selector | Lever |
| Foot Pressure Adjustment | Manual |
| Foot Controller Included | Yes |
| Knee Lifter Compatible | No |
| Case Included | Yes (Soft Cover) |
| Sewing Speed | 1500SPM |
| Included Sewing Feet | 1 |
| Free-arm | No |
| Shipping Weight | 19.0000kg |
| Shipping Width | 0.490m |
| Shipping Height | 0.400m |
| Shipping Length | 0.380m |
| Shipping Cubic | 0.074480000m3 |
Baby Lock warranty & extended warranty:
1 year on defective parts and labour (4 year extended warranty available. T&Cs Apply)2 years on electronic components
To find out more information on how to claim your extended warranty and see the conditions not covered by warranty, visit the manufacturer's website here.
