The Evolution is an eight thread overlocker/coverstitch machine including:
Features:
-
79 stitch options
-
ExtraordinAir Treading
-
Automatic Thread Delivery System
-
Heavy Duty cutting system
-
Exclusive wave stitch and reverse wave stitch
-
Automatic rolled hem stitch
-
Coverstitch options and more!
What's In The Box
- Instruction manual
- Quick reference threading guide
- Combination foot control & power cord
- Package of assorted sized needles Organ ELx705CF
- Flat table for chain/cover stitching
- 2 x Guide fixing screws for table
- Lint brush/needle insert tool
- Manual needle threader
- Allen screwdriver
- Tweezers
- Upper cutting blade for replacement
- Screwdriver
- Looper threading tool
- 2 x Overlock needle screws
- 2 x Chain/cover stitch needle screws
- 8 x Thread nets
- 8 x Spool caps with sponge
- 8 x Spool caps
- Machine cover
- 8 x Cone holders
- Standard grooved presser foot
- Thread stand extension
- Thread guide extension
Specifications | |
---|---|
Machine Type | 8-Thread Overlocker |
Machine Type | Coverstitch |
Threading System | ExtraordinAir™ |
Key Technology | |
Number of Threads | 8 |
RevolutionAir™ Threading – Needles & Loopers | |
ExtraordinAir™ Threading | |
NEW JetAir™ (easier looper threader engagement) | |
JetAir™ Threading | |
Tension System | Auto Thread Delivery (ATD) System |
Lighting | 3 LED |
Throat Space | - |
True 2 to 1 ratio differential feed - ranging from 0.6 to 2 | |
Knee Lift (Presser Foot) | |
Variable Speed Control (easily set the maximum speed) | |
Exclusive Fabric Support System | |
Vertical Needle System – minimises needle deflection | |
Advanced Features | |
Combination Stitch Options | 87 |
Coverstitch: triple, wide (6mm), narrow (3mm) & single chain stitch | |
Overlocking stitch Options: 4/3/2 Thread | |
Exclusive Wave Stitch and Reverse Wave Stitch | |
Automatic rolled hem stitch with the turn of a dial | |
Flatlock stitch option for seaming and decorative effects | |
Stitch Length | 0.75 to 4mm |
Stitch Width – Overlocking | 1.5 to 7.5mm |
Stitch Width – Expressive (overlocking & coverstitch combined) | Up to 16mm |
Heavy duty cutting system – cut thick fabrics easily | |
Presser Foot Pressure Adjustment | Adjustable Screw |
Presser Foot Height | 4.5mm |
Sewing speed (stitches per minute) | up to 1500 |
Convenience Features | |
Thread Stand Tray with Magnet | |
Colour Coded Quick Reference Threading Guide | |
Built-in Manual Needle Threader | |
Position of presser foot lever | Rear |
Included Foot | Grooved Foot |
Built in Thread Cutter | |
Guard plate for needle screws | |
Built in Accessory Storage | |
Saftey Switches | 2 |
Needle Drop Tray | |
Electronic Foot Control | |
Other Features | |
Needle Type | EL 705 CF |
Machine Weight | 8.5KG |
Made in Japan & 5 Year Conditional Warranty | |
Optional Accessories | |
Optional Feet Available | 16 |
Optional Attachments | 13 |
Compatibility with Knit Binders/Lap Seam Binder | |
Clear Extension Table Compatibility | CT-1 |
SKU | BLE8W-2 |
---|---|
Brand | Baby Lock |
Number Of Threads | 2-8 |
Max Number Of Threads | 8 |
Differential Feed | 0.5mm to 2.00mm Ratio |
Number Of Stitch Combination Options | 87 |
Flatlocking | Yes |
Rolled Hemming | Yes |
Cover Hem | Yes |
Top Cover Hemming | No |
Chain Stitch | Yes |
Wave Stitch | Yes |
Threading Chart | Yes |
Adjustable Cutting Width | 3 to 7.5mm |
Adjustable Stitch Length | 0.75mm to 4.0mm |
Retractable Upper Knife | Yes |
Two Thread Converter | Yes |
Waste Tray Included | No |
Tension System | Auto Thread Delivery (ATD) System |
Air Threading (looper) | ExtraordinAir |
Quick Change To Rolled Hem | Yes |
Mechanical Warranty | 5 Years |
Machine Weight | 9.5kg |
Machine Height | 270mm |
Machine Length | 350mm |
Machine Depth | 360mm |
Workspace | 2" |
Lighting Type | LED |
Number Of Lights | 3 |
USB Port | No |
Wi-Fi Enabled | No |
Thread Cutter | No |
Needle Threading | No |
Stitch Selector | Lever |
Foot Pressure Adjustment | Manual |
Foot Controller Included | Yes |
Knee Lifter Compatible | No |
Case Included | Yes (Soft Cover) |
Sewing Speed | 1500SPM |
Included Sewing Feet | 1 |
Free-arm | No |
Shipping Weight | 19.0000kg |
Shipping Width | 0.490m |
Shipping Height | 0.400m |
Shipping Length | 0.380m |
Shipping Cubic | 0.074480000m3 |

Baby Lock warranty & extended warranty:
1 year on defective parts and labour (4 year extended warranty available. T&Cs Apply)2 years on electronic components
To find out more information on how to claim your extended warranty and see the conditions not covered by warranty, visit the manufacturer's website here.
